Enclosed Printing space with larger build volume enhance the printing quality, out of box, no need assemble, optional auto power off feature is safer for children.Patented printing platform with excellent adhesion whilst printing and pop off once it cools down. The sensor triggers the machine to pause prints and set off an alarm when filament run out.
- Print Quietly
- Optional auto shut off to save power when finish printing.
- Printing Platform
- Grips the vast majority of print materials with ease when hot, releasing them with little resistance when cold.
- Sensitive Touch Screen
- Full color, multi-language, user friendly UI.
- Filament Sensor
- Auto warning if filament runs out or break. Intelligence help to save time and filaments.
- Technical Specifications
- ● Printing Technology: FDM (Fused Deposition Modeling)
- ● Layer Resolution: 0.05-0.3 mm
- ● Positioning Accuracy: X/Y 0.0125mm Z 0.002mm
- ● Supported Print Materials: PLA, TPU,ABS, HIPS, Wood
- ● Print Speed: 20~80mm/s (suggested 50mm/s)
- ● Nozzle Diameter: 0.4 mm/1.75 mm
- ● Build Size:270mm(L)×205(W)×205mm(H)
- ● Operational Extruder Temperature: Max 260ºC
- ● Operational Print Bed Temperature: Max 100ºC
- ● Extruder Quantity: Single
- ● Input Formats: .STL, .OBJ, .DAE, .AMF
- ● Ambient Operating Temperature: 8ºC – 40ºC
- ● Connectivity SD Card, USB Port (expert users only)
- ● Package Weight: 18.5kg
- Auto Power Off
- Optional auto shut off and save power when finish printing.
- Short Distance Extruder
- Design in short distance extruding, stronger torque, smoother extruding and compatible with TPU.
- Seal and Mute
- New UI, smooth running, easy operating. User friendly.
Parts List
Plier
PLA filament
Scraper
Tool set
Card reader
Glove
SD card
User manual
Tweezers
Power cord
USB cable
Screw(M5)*10
|
|
|
|
| Printing Technology | FDM (Fused Deposition Modeling) | FDM (Fused Deposition Modeling) | FDM (Fused Deposition Modeling) |
| Build Area | 8.27”x8.27”x8.07” (210x210x205mm) | 8.27”x8.27”x8.07” (210x210x205mm) | 10.63”x8.07”x8.07” (270x205x205mm) |
| Print Materials | PLA, ABS, HIPS, PETG, Wood | PLA, ABS, HIPS, PETG, Wood and TPU | PLA, ABS, HIPS, PETG, Wood and TPU |
| Titan Extruder & Suspended Filament Rack |
✗ | ✔ | ✔ |
-
- i3 Mega
- FDM (Fused Deposition Modeling)
- Build Area: 210x210x205mm
- Filament: PLA, ABS, HIPS, PETG,
Wood - Mega Extruder
None Suspended Filament Rack
-
- i3 Mega S
- FDM (Fused Deposition Modeling)
- Build Area: 210x210x205mm
- Filament: PLA, ABS, HIPS, PETG,
Wood and TPU - Titan Extruder
Suspended Filament Rack
-
- 4Max Pro
- FDM (Fused Deposition Modeling)
- Build Area: 270x205x205mm
- Filament: PLA, ABS, HIPS, PETG,
Wood and TPU - Titan Extruder
Suspended Filament Rack
Anycubic Care
Firmware
1. 4Max Pro Firmware V1.1.7
Driver
1. 4Max_Win for Windows
2. 4Max_Mac for Mac OS
2. 4Max_Mac for Mac OS
Slicer
1. Cura_15.04.6_Mac for Mac
2. Cura_15.04.6_Win for Win
2. Cura_15.04.6_Win for Win
Test model
1. Test_model_1
please click on it to download.
please click on it to download.
Manual
1. 4Max_Pro_Manual
please click on it to download.
please click on it to download.
Service
We offer excellent after-sales service. Please click here for details.
