Sorry, Anycubic Mega SE is sold out.
Upgrade to our latest model Anycubic Kobra Neo.
Product Description
- Fast Heat-up Bed
- The hot bed can reach 100 degrees Celsius in about five minutes.
- Quick Assembly
- Comes in only a few pieces with no assembly hassle.
- Stepper drivers
- Significantly reduce the noise when printing.
- Ultrabase Build Surface
- Enhanced Adhesion and Easily remove the print with your hands.
- Technical Specifications
- ● Printing Technology: FDM (Fused Deposition Modeling)
- ● Build Size: 220mm(L)×220(W)×250mm(H)
- ● Layer Resolution: ±0.1mm
- ● Positioning Accuracy: X/Y/Z 0.0125/0.0125/0.002mm
- ● Extruder Quantity: Single
- ● Nozzle Diameter: 0.4 mm
- ● Print Speed: 20~100mm/s (suggested 60mm/s)
- ● Supported Materials: PLA, TPU, ABS, HIPS, PETG
- ● Ambient Operating Temperature: 8°C – 40°C
- ● Operational Extruder Temperature: max 255°C
- ● Connectivity: Trans-flash Card; USB cable(expert users only)
- ● Input rating: 100V/240V AC, 50/60Hz
- ● output rating: 24V/15A（360W）
- ● Printer Dimensions: 505mm×431mm×607mm
- ● Weight: ~7kg
- Easy leveling
- Automatically locate the leveling spot and quickly locate the corners of the print platform during leveling.
- Large build volume
- Makes it an ideal size for desktop storage and use.
- TMC2208 stepper drivers
- Silence the 3D printer. Significantly reduce the noise when printing.
- Capricorn PTFE tube
- Its advantages are high resistance to high temp, corrosion and ageing, as well as non-stick surface and self-lubrication.
- Auto-resume from power loss
- Easily continue printing from power failure or pause, saves time and filament.
- Protection for hot bed wire
- Reduces the damages caused by wobbling of hot bed wire during hot bed movement.
- Fast heat-up bed
- The hot bed can reach 100 degrees Celsius in about five minutes. Greatly improved the printing efficiency.
- Double gear extrusion
- Strong extruder ensures a smoother filament guiding. Compatible with flexible filaments like PLA.
- Ultrabase build surface
- The Ultrabase allows your prints to stick to the heated bed while the prints can be easily removed when cooling.
Parts List
Assembly instruction
Card reader
Control Box
cable
Filament
Filament holder
Memory card
Plier
Power cord
Scraper
Screws(M4)-*20 2pcs
Screws(M5)-*6 2pcs
T-nut-1PCS
Tool kit
|
|
|
|
| Printing Technology | LCD-based SLA Printing | LCD-based SLA Printing | FDM (Fused Deposition Modeling) |
| Build Area | 130x80x165mm | 192x120x245mm | 245x245x260mm |
| Print Materials | 405nm UV Resin | 405nm UV Resin | PLA, ABS, HIPS, PETG, Wood and TPU |
| Illuminant | Matrix | Matrix | None |
-
- Photon Mono
- LCD-based SLA
- Build Area: 130x80x165mm
- Filament:405nm UV Resin
- Diffusion: Matrix
-
- Photon Mono X
- LCD-based SLA
- Build Area: 192x120x245mm
- Filament:405nm UV Resin
- Matrix: Matrix
-
- Vyper
- FDM (Fused Deposition Modeling)
- Build Area: 245x245x260mm
- Filament: PLA, ABS, HIPS, PETG,
Wood and TPU
