Sorry, Anycubic Photon Mono is sold out.
Upgrade to our latest model Anycubic Photon Mono 2.
Product Description
FEP Film for Photon Mono here https://www.anycubic.com/products/fep-film-for-photon-mono-sla-lcd-3d-printer
- 6″ 2K Monochrome LCD
- A much longer lifespan: It’s s 4 times longer than color LCD.
- Quick FEP Replacement
- Easy and quick to replace the FEP.
- Fast Printing Speed
- With a monochrome screen, the printer can use less energy while printing faster.
- High Quality Z-axis
- High Quality Z-axis Rail Structure & Stepper Motor.
- Technical Specifications
- ● System : ANYCUBIC Photon Mono
- ● Operation : 2.8 inch Touch Screen
- ● Software : ANYCUBIC Photon workshop
- ● Connectivity : USB
- ● Technology: LCD-based SLA
- ● Light-source: high-quality filament（wavelength 405nm）
- ● XY Res.: 0.051mm 2560*1620（2K）dd>
- ● Z Axis Res.: 0.01mm
- ● Layer Res.: 0.01 ~ 0.15mm
- ● Printing Speed: MAX 50mm/h
- ● Rated Power: 45W
- ● Printer Size : 227mm(L)*222mm(W)*383mm(H)
- ● Build Volume: 130mm(L）*80mm(W）*165mm（H）
- ● Material: 405nm UV Resin
- ● Net Weight: ~4.5kg
- High Quality Z-axis Rail
- It improves stability while in motion and reduces the risk of layer shifting.
- Quick FEP Replacement
- Easy and quick to replace the FEP.
- Top Cover Detection
- The printer can be set to stop printing immediately after opening the cover.
- More Creative Space
- For freedom to make
- Anycubic Slicer Software
- New features are added to the software. Supports up to 16x anti-aliasing. Fast slicing, Hollowing, Split Model, Text Paste
- 2K Monochrome LCD
- The exposure time is reduced to 1.5 seconds. A much longer lifespan: You can print up to 2000 hours with it, which is 4 times longer than color LCD.
- UV-blocking Top Cover
- With the transparent cover, you can watch your prints while still blocking 99.95% of the UV light.
- New Matrix Parallel Light Source
- It has a more uniform exposure, higher efficiency and better heat dissipation.
- High Quality Power Supply
- UL certification, CE marking, and ETL certification
Parts List
User Manual
Tool set
USB Drive
Scraper
Resin Vat
Platform
Service Card
Glove
Funnel
Power Adapter
|
|
|
|
| Machine Weight | 4.5kg | 4.3kg | 11kg |
| Machine Size | 383*227*222mm | 383x227x222mm | 475x290x270mm |
| LCD Resolution | 2560x1620px(2k) | 3840x2400px(4k) | 5760x3600px(6k) |
| LCD Size | 6.08’’ monochrome | 6.23’’ monochrome | 9.25’’ monochrome |
| XY Resolution | 51 microns | 35 microns | 34 microns |
| Z axis Accuracy | 10 microns | 10 microns | 10 microns |
| Build volume | 165*130*80mm(1.72L) | 165x132x80mm(1.74L) | 245x197x122mm(5.89L) |
| Max.Printing Speed | 50mm/h | 50mm/h | 80mm/h |
-
- Photon
- LCD-based SLA
- Build Area: 115x65x155mm
- Filament:405nm UV Resin
- Diffusion Illuminant
- Single Z-axis
-
- Photon S
- LCD-based SLA
- Build Area: 115x65x165mm
- Filament:405nm UV Resin
- Matrix Illuminant
- Double Z-axis
-
- 4Max Pro
- FDM (Fused Deposition Modeling)
- Build Area: 270x205x205mm
- Filament: PLA, ABS, HIPS, PETG,
Wood and TPU - Titan Extruder
Suspended Filament Rack - Single Z-axis
